high strength low alloy steel

Ocean Welding AWS E8015-G low alloy steel electrode is a high-performance welding material designed for medium carbon steel and low alloy steel structure welding. It adopts a low hydrogen iron powder coating formula and has excellent welding process performance and mechanical properties. The product is produced in strict accordance with international standards, with diameters of 2.5mm, 3.2mm and 4.0mm to meet the welding needs of workpieces of different thicknesses.

Core advantages

• Excellent mechanical properties: tensile strength of deposited metal ≥550MPa, excellent impact toughness (Ak≥27J at -30℃)
• Low hydrogen properties: diffusible hydrogen content ≤8ml/100g, effectively preventing cold cracks in welding
• Strong process adaptability: DC reverse power supply can be used, all-position welding, beautiful weld formation
• Cost-effectiveness advantage: 5kg/ctn, 20kgs/ctn various packaging specifications, 1 ton minimum order to enjoy wholesale price

• Technical Parameters

  item	Standard requirements	Measured value
  Chemical composition of deposited metal (%)
  C	≤0.12	0.08-0.10
  Mn	≥1.0	1.2-1.4
  Si	0.3-0.7	0.4-0.6
  S	≤0.035	≤0.025
  P	≤0.035	≤0.020
  Mechanical properties
  Tensile strength σb (MPa)	≥550	580-620
  Yield strength σs (MPa)	≥460	480-520
  Elongationδ(%)	≥22	24-26

Packaging & Delivery

 Welding of medium carbon steel structures and low alloy  steel structures.

Application areas

• Engineering machinery: welding of structural parts of excavators, loaders, and cranes
• Pressure vessels: welding of medium and low pressure storage tanks, boiler pipelines
• Bridge construction: welding of steel structure bridge nodes
• Power equipment: welding of generator sets and transformer casings
• Mining machinery: welding of wear-resistant parts such as crushers and conveyors

Welding process guide

1. Preparation before welding: remove rust, oil and moisture from the workpiece surface, dry the welding rod at 350-400℃ for 1-2 hours, put it in an 80-100℃ insulation cylinder for use
2. Welding parameters (taking 3.2mm welding rod as an example):
Welding current: 90-120A
Arc voltage: 24-28V
Welding speed: 150-200mm/min
3. Precautions: When the wind speed is greater than 8m/s, windproof measures should be taken, and the temperature between layers should not be lower than 150℃ during multi-layer welding
