AWS E6013 Welding Rod
AWS E6013 Welding Electrode
Description
Carbon Steel Welding Electrode E6013 is a popular choice for welding carbon steel materials due to its excellent features. This electrode is easy to use and produces high-quality welds that are strong and ductile.
Here are some of its key features:
1. High-quality welds: E6013 produces welds that are strong and ductile, making it an ideal choice for welding carbon steel materials. The welds produced by this electrode have excellent penetration and can withstand high stress conditions.
2. Easy to use: This electrode is easy to use and can be used by both professional welders and beginners. Its smooth arc and stable burning make it an ideal choice for welding in any position.
3. Low spatter: E6013 produces low spatter, which makes it easy to clean and produces less abrasive particles in the air.
4. Low hydrogen content: This electrode has a low hydrogen content, which reduces the risk of hydrogen-induced cracking.
E6013 has a wide range of applications, including general fabrication, construction, shipbuilding, and repair and maintenance works. It is also used in the automotive industry and for the repair of agricultural machinery.
Attention
When using E6013, it is important to follow certain precautions to ensure safety and optimal results. The following are some of the key precautions to take:
1. Keep the electrode dry: Moisture can reduce the quality of the weld and increase the risk of porosity. Therefore, it is important to keep the electrode dry before use.
2. Use the correct amperage: E6013 has a recommended amperage range that should be followed to obtain optimal results.
3. Use the correct polarity: E6013 can be used with both direct current (DC) and alternating current (AC) power supplies. However, it is important to use the correct polarity for optimal results.
4. Clean the surface properly: It is important to clean the surface of the material before welding to ensure good penetration and a strong weld.
In conclusion, Carbon Steel Welding Electrode E6013 is an excellent choice for welding carbon steel materials due to its excellent weld quality, ease of use, and versatility. Follow appropriate precautions when using it to ensure safety and optimal results.
Chemical Composition of WIre;(%)
| C | Mn | SI | P | S | |
| Standard | ≤0.12 | 0.5-0.9 | ≤0.5 | ≤0.035 | ≤0.035 |
| Test Result | 0.067 | 0.54 | 0.09 | 0.018 | 0.019 |
Mechanical Properties of Deposited Metal
|
Tensile Strength σb(Mpa) |
Yield Point σ0.2(Mpa) |
Elongation δ5 (%) |
Akv Impact（-30℃） (J) |
|
| Standard | 400-560 | ≥330 | ≥22 | ≥27 |
| Test Result | 480 | 410 | 26 | 87 |
Recommended Current( DC*)
| Diameter(mm) | Φ2.0 | Φ2.5 | Φ3.2 | Φ4.0 | Φ5.0 |
| Length(mm) | 300 | 300 | 350 | 350 | 400 |
| Current(A) | 40-70 | 60-90 | 80-130 | 150-190 | 180-250 |
