6010 Welding Rod
DESCRIPTION:
AWS E6010 welding rod is a high cellulose sodium type carbon steel welding electrode for vertical-down welding.It shows a very good performance in welding of all positions, especially vertical-down welding.The welding performance are excellent:deep penetration,fewer slag,slag easy to remove,high welding efficiency and good weld shape etc.The electrode forms double sides by one side welding.
APPLICATION:
Suitable for welding root passes,hot passes,filler and cover passes as well as for capping of general pipes and similar structures.
ATTENTION:
◆Generally,welding electrodes do not need bake before welding.
◆If damped,the electrodes should be baked for 0.5-1 hours at the temperature of 70-80℃ before welding.
Chemical Composition of Deposited Metal: （%）
C | Mn | Si | P | S | |
Standard | - | - | - | ≤0.040 | ≤0.035 |
Typical | 0.091 | 0.55 | 0.18 | 0.015 | 0.013 |
Mechanical Properties of Deposited Metal
Tensile Strength | Yield Point | Elongation | Akv Impact（-30℃） | |
σb(Mpa) | σ0.2(Mpa) | δ5 (%) | (J) | |
Standard | ≥420 | ≥330 | ≥22 | ≥27 |
Typical | 500 | 405 | 28 | 96 |
Recommended Current( DC*)
Diameter(mm) | Φ 2.5 | Φ3.2 | Φ 4.0 | Φ 5.0 |
Length(mm) | 300 | 350 | 400 | 400 |
Flat,Horizontal | 60-90 | 70-110 | 110-150 | 150-200 |
Current(A) | ||||
Vertical,Overhead | 50-80 | 60-100 | 100-140 | 140-180 |
Current(A) | ||||
