Lincoln 6010 Welding Rod
lincoln 6010 welding rod
DESCRIPTION:
China lincoln 6010 welding rod Is special carbon steel electrode for the vertical downward welding of the cellulose potassium type welding rod, AC/DC both ok
APPLICATION:
It is suitable for butt, angle connection and lap welding of thin plate structure. Such as power plant flue, air duct, transformer oil tank, hull and vehicle outer plate carbon steel structure.
Chemical Composition of Deposited Metal: （%）
C | Mn | Si | S | P | |
Standard | - | - | - | ≤0.035 | ≤0.04 |
Typical | 0.09 | 0.65 | 0.20 | 0.023 | 0.025 |
Mechanical Properties of Deposited Metal
Tensile Strength | Yield Point | Elongation | Akv Impact（-30℃） | |
σb(Mpa) | σ0.2(Mpa) | δ5 (%) | (J) | |
Standard | ≥420 | ≥330 | ≥22 | ≥27 |
Typical | 530 | 415 | 26 | 76 |
Recommended Current( AC、DC)
Diameter(mm) | Φ 2.5 | Φ3.2 | Φ 4.0 | Φ 5.0 |
Length(mm) | 300 | 350 | 400 | 400 |
Current(A) | 30-50 | 70-100 | 90-140 | 150-200 |
Please select our E6010 welding rod, same as Lincoln quality
Free samples for you testing
