ER-308L Stainless Steel Welding Wire
Model: AWS ER-308L
Product Positioning: Mid-to-high-end industrial-grade stainless steel welding material, focusing on quality-sensitive segmented scenarios. It provides a cost-effective solution for 1.4306 (304L) stainless steel welding and welding under extreme temperature or low-hydrogen working conditions.
I. Basic Product Parameters
| Category | Detailed Specifications |
|---|---|
| Material | Stainless Steel |
| Diameter Specifications | 0.8mm, 0.9mm, 1.0mm, 1.2mm, 1.6mm |
| Applicable Processes | MIG (Metal Inert Gas Welding), TIG (Tungsten Inert Gas Welding) |
| Packaging Specifications | Standard: 1kg/roll, 5kg/roll, 15kg/roll; Customized packaging available |
| Weight Options | 5kg, 15kg (Basic packaging weight) |
| Delivery Cycle | 25 days per batch |
| Shipping Ports | Shanghai Port, Ningbo Port, Yiwu Port |
| Certification | ISO 9001-2008, CE, SGS |
| Value-added Services | OEM customization supported, free samples provided |
II. Core Properties of Deposited Metal
1. Chemical Composition (%)
| Chemical Composition | Standard Limit | Actual Sample Value | Core Function |
|---|---|---|---|
| Carbon (C) | ≤0.03 | 0.025 | Low-carbon design reduces carbide precipitation, prevents intergranular corrosion, and improves weld corrosion resistance |
| Manganese (Mn) | 1.0-2.5 | 1.63 | Optimizes weld bead fluidity, enhances weld toughness and structural strength |
| Silicon (Si) | 0.3-0.65 | 0.43 | Deoxidizes and removes gas, reduces the risk of porosity defects, and improves weld density |
| Chromium (Cr) | 19.5-22.0 | 20.05 | Forms a passive film, resists oxidation and chemical medium erosion, and is a core corrosion-resistant element |
| Nickel (Ni) | 9.0-11.0 | 10.2 | Cooperates with chromium to enhance corrosion resistance and improves the low-temperature toughness of the weld |
| Copper (Cu) | ≤0.75 | 0.02 | Assists in improving corrosion resistance, with composition control accuracy far exceeding the standard |
| Molybdenum (Mo) | ≤0.75 | 0.02 | Avoids affecting the stability of the welding process and ensures uniform weld bead formation |
2. Mechanical Properties
| Performance Indicator | Standard Requirement | Actual Sample Value | Performance Advantage |
|---|---|---|---|
| Tensile Strength | ≥550MPa | 610MPa | Can withstand higher tensile loads, suitable for high-strength structural welding |
| Elongation | ≥35% | 41% | Excellent plasticity and toughness, reducing the risk of stress cracks after welding |
III. Core Product Features
Quality Assurance: Certified by ISO 9001-2008, CE, and SGS. Full-process quality control from raw material selection to finished product inspection ensures stable performance of each batch of welding wire.
Strong Process Adaptability: Supports two mainstream welding processes (MIG/TIG) and covers diameter specifications from 0.8mm to 1.6mm, meeting the needs of different scenarios such as fine thin-wall welding, conventional structural welding, and multi-pass welding.
Extreme Temperature Resistance: The weld can work stably in the temperature range of -195℃ to +350℃, without brittleness at low temperatures and stable performance at medium temperatures. It is suitable for special working conditions such as low-temperature storage tanks and medium-temperature pipelines.
Low-hydrogen Welding Solution: When used with BOHLER BB 802 fluorine-based sintered flux, it can achieve low flux consumption and low-hydrogen welds, significantly reducing the risk of delayed cracks. It is suitable for key structures such as pressure vessels and chemical equipment.
Flexible Service Solutions: OEM customization is supported, and packaging can be adjusted according to needs. Free samples are provided to facilitate the verification of welding effects before bulk purchase. Fast delivery within 25 days and multi-port shipping cover domestic and international markets.
IV. Application Scenarios
| Application Field | Specific Scenarios | Adaptation Reasons |
|---|---|---|
| Stainless Steel Welding | Multi-pass welding, flat butt welding, and fillet welding of 1.4306 (304L) low-carbon austenitic stainless steel | The weld bead has a smooth appearance, no slag residue, easy slag cleaning, and matches the compositional characteristics of 304L stainless steel |
| Equipment Manufacturing | Food machinery, medical equipment, new energy energy storage tanks | Low carbon and low impurities, avoiding metal ion precipitation, and meeting the requirements for cleanliness and corrosion resistance |
| Pressure Equipment & Chemical Industry | Pressure vessels, chemical pipelines, storage equipment for corrosive media | High tensile strength (610MPa), low-hydrogen welding solution prevents cracks, and resists corrosive environments |
| Low-temperature/Medium-temperature Engineering | LNG storage tanks, refrigeration equipment, medium-temperature heating pipelines | Works stably in the temperature range of -195℃ to +350℃, adapting to extreme temperature working conditions |
V. Market Positioning
1. Target Market
Focus on the mid-to-high-end industrial welding market, covering core "quality-sensitive" fields:
Equipment manufacturing fields with clear standards for weld corrosion resistance and strength (food machinery, medical equipment);
Pressure equipment and chemical industries requiring low-hydrogen welding and high safety;
Low-temperature/medium-temperature engineering fields with extreme temperature working condition requirements.
2. Competitive Advantages
| Comparison Dimension | AWS ER-308L | Imported Brands (Lincoln, Bohler) | Domestic Low-end & Mid-end Brands |
|---|---|---|---|
| Price | Cost-effective | High (30%-50% more expensive) | Low |
| Delivery Cycle | 25 days | 30-45 days | 15-20 days (but unstable quality) |
| Certification | ISO 9001 + CE + SGS | Complete | Mostly incomplete |
| Customization Service | OEM/packaging customization supported | Slow response | None |
| Performance Stability | Sample values exceed standards | Stable | Large composition fluctuation |
3. Core Customers
Direct Manufacturing Enterprises: Medium-and large-sized equipment manufacturers, pressure vessel factories, and chemical equipment companies (with a single purchase volume of 50-500kg, focusing on long-term cooperation and stable quality);
Traders/Distributors: Welding material traders covering overseas (Southeast Asia, the Middle East) and domestic regional markets (requiring compliance certification and flexible shipping solutions).
VI. Purchase & Consultation
Sample Application: Free samples are available; contact us to obtain a welding test plan.
OEM Cooperation: Brand customization and packaging customization are supported; specific requirement plans need to be provided.
Contact Information: Visit the official website (www.dayangweldings.com) or contact brand customer service to get the latest quotation and delivery plan.
