Welding Torch



The DY-B10 welding gun is designed for budget-sensitive customers. It uses a lightweight all-copper movement and ergonomic handle, and is compatible with MIG/TIG welding processes. It has passed 100,000 fatigue tests and is suitable for a variety of base materials such as carbon steel, stainless steel, and aluminum alloy. It is widely used in maintenance, sheet metal processing, DIY and other scenarios.



Packaging Details:	1PC/CARTON BOX
Delivery Detail:	20-25days





Extreme cost-effectiveness

• 60% of the price of similar products, standard 3-meter cable + consumable parts set

Durability design

• The conductive nozzle is made of chromium-zirconium-copper alloy, and the service life is increased by 50%
• The cable is temperature-resistant from -40℃ to 120℃, and the number of bending resistance is ≥5000 times

Easy to operate

• Quick-plug interface, installation is completed in 30 seconds
• Adjustable airflow control valve, suitable for 0.8-1.6mm welding wire





• Small processing workshops: daily weldment repair
• Auto repair: body sheet metal welding
• Door and window manufacturing: aluminum alloy frame connection
• DIY enthusiasts: handmade product production
• Agricultural machinery: agricultural machinery parts repair



Item	Parameter Value	Description
Applicable process	MIG/TIG (needs welding machine)	Supports DC/pulse current
Rated current	200A (continuous load 60%)	Meets conventional welding requirements
Applicable wire diameter	0.8-1.2mm (MIG)	Compatible with mainstream welding wire specifications
Cooling method	Air cooling + heat sink fins	No external water cooling equipment required
Cable length	3 meters (can be customized to extend to 5 meters)	Standard 3 meters to meet conventional operating distance





1. Installation steps
① Connect the welding machine output terminal to the welding gun interface
② Insert the welding wire to 3mm from the front of the conductive nozzle
③ Adjust the gas flow to 8-12L/min (MIG welding)
2. Recommended welding parameters

Base material thickness	Current range	Voltage regulation	Wire feeding speed
1-2mm	80-120A	18-22V	3-5m/min
3-5mm	120-180A	22-26V	5-8m/min





• Wear a UV-proof mask (shading number 10-12)
• Maintain ventilation during welding to avoid carbon monoxide poisoning



• Clean spatter from the contact tip every 100 hours of welding
• Regularly check the wear of the cable insulation layer
