ER312 Stainless Steel Welding Wire
Product Name: ER312 Stainless Steel Welding Wire
Application: For welding of dissimilar steels, the crack sensitivity is low, so welding of steel materials such as cladding steel and stainless steel lining is difficult or prone to pores
Product Advantages
ER312 Stainless Steel Welding Wire performs well in harsh environments and high temperature conditions due to its excellent corrosion resistance and crack resistance. At the same time, its wide process adaptability and high-quality welding effect ensure the smooth welding process and high-quality welds, thereby extending the service life of the equipment and improving the overall performance.
Corrosion resistance
ER312 welding wire has good corrosion resistance and can resist corrosion by sulfuric acid, sulfurous acid and organic acids. This allows the weld to maintain good performance in harsh environments and extend the service life of the equipment.
Crack resistance
Due to its ultra-low carbon content and high molybdenum content,Stainless steel welding wire can prevent intergranular corrosion, no heat treatment is required after welding, and high high temperature strength. This allows the weld to maintain good performance in high temperature environments and reduce the occurrence of cracks.
Adaptability
Stainless steel welding wire is suitable for a variety of welding processes, including argon arc welding (TIG), gas shielded welding (MIG), etc. This allows the welding wire to perform well in different welding occasions and improve the flexibility of welding.
Welding quality
ER312 welding wire has good arc stability and weld bead beauty, and the weld is well formed after welding. This makes the welding process smoother, the weld quality is higher, and the occurrence of welding defects is reduced.
Product Features
Chemical composition
The chemical composition of stainless steel welding wire mainly includes carbon (C) ≤ 0.12%, manganese (Mn) 1.00-2.00%, silicon (Si) ≤ 0.90%, chromium (Cr) 11.50-13.50%, nickel (Ni) 8.50-10.50%, and molybdenum (Mo) 0.75-1.25%.These ingredients give the welding wire good corrosion resistance and high temperature strength.
Physical properties
Its density is 7.85 g/cm³, thermal expansion coefficient is 10.4 μm/m·K (20-100℃), and thermal conductivity is 16.2 W/m·K (100℃).These physical properties enable it to maintain stable performance in high temperature environments.
Welding performance
ER312 stainless steel welding wire has good arc stability and weld bead aesthetics, no heat treatment is required after welding, and high temperature strength.This makes the welding process smoother and the weld quality higher.
Chemical composition
| Item |
C
|
Mn
|
Si
|
Cr
|
Ni
|
Mo |
P
|
S
|
Cu |
|---|---|---|---|---|---|---|---|---|---|
|
AWS Standard
|
0.15
|
1.00~2.50
|
0.30-0.65
|
28.00-32.00
|
8.00-10.50
|
0.75 |
0.03
|
0.03
|
0.75 |
Mechanical properties
|
Mechanical properties
|
Yield strength MPa
|
Tensile strength MPa
|
Elongation % |
|---|---|---|---|
|
AWS Standard
|
≥181 MPa
|
≥515 MPa
|
≥39% |
Application fields
- Mechanical manufacturing: ER312 welding wire is widely used in the mechanical manufacturing industry for welding various stainless steel structural parts and mechanical parts. Its good welding performance and corrosion resistance make it an indispensable welding material in mechanical manufacturing.
- Chemical equipment: In the manufacture of chemical equipment, stainless steel welding wire is used for welding reactors, storage tanks, p stainless steel welding wire Its corrosion resistance and high temperature strength enable it to withstand the working conditions of chemical equipment in harsh environments.
- Food processing equipment: ER312 welding wire is also used for welding food processing equipment, such as food conveyor belts, storage tanks, etc. Its corrosion resistance and hygienic properties enable it to meet the strict requirements of the food processing industry.
- Nuclear industry: In the nuclear industry, stainless steel welding wire is used for welding nuclear 12 stainless steel welding wire e containers, etc. Its high temperature strength and corrosion resistance enable it to meet the high requirements of the nuclear industry for materials
Welding process
- Argon arc welding (TIG): ER312 welding wire is suitable for argon arc welding and has good arc stability and weld bead formation. TIG welding can provide high-quality welds and is suitable for occasions with high welding quality requirements.
- Gas shielded welding (MIG):ER312 stainless steel welding wire is also suitable for gas shielded welding and has good deposition performance and anti-porosity ability. MIG welding is suitable for welding medium and thick plates and can improve welding efficiency.
- Welding parameters: According to the thickness of the parent material and the welding position, select the appropriate welding current and voltage. For example, for a thinner base metal, a smaller welding current and voltage should be selected to avoid burn-through; for a thicker base metal, a larger welding current and voltage should be selected to ensure penetration of the weld.
why choose our products
We have our own modern factory, which is our core competitiveness.
The factory is equipped with internationally advanced production equipment, has formed a professional and sophisticated technical team, and strictly follows international quality standards for production.
From the careful selection of raw materials, to each process in the production process, to the strict quality inspection of the finished product, every link is strictly controlled to ensure that each ER312 stainless steel welding wire meets high quality standards.
The strong large-scale production capacity enables us to respond quickly to market demand and provide you with a stable and reliable supply, completely avoiding the impact of insufficient supply on your production progress.
